The final exam will be in the form of a project that’s presented, based on the business scenario that you used for the data modeling colloquium.
You are to give a PowerPoint presentation with the following five charts:
Title: Your name, business scenario name
Requirements: a one-page summary of the requirements in bullet form.
Chen ERD: a one-page Chen ERD produced by ERDPlus for your business scenario.
Your Chen ERD
- must have no generated keys,
- every entity type must have a natural key,
- the natural key must be shown by underlining,
- many-many relationships must be symbolized with diamonds and not associate entities or entities, and
- many-many relationships must not show as attributes the identifiers of the entity types participating in the relationship.
Relational ERD: a one-page ERD showing the tables in your database. You may use a generated key for any composite keys of three or more columns that are used as foreign keys.
APEX App: a link to your APEX application, that you are to demonstrate live.
Your APEX application
- will, in most cases, have two different screens for two different types of users, one a customer and one an employee of the business
- is to present user-friendly screens for carrying out the operations that are specified in your problem statement; that is, end users, either company employees or customers, are not to be concerned with entering information that’s unfamiliar to them.
- should carry out its business functions and give feedback to the user that the function is complete.
